Geosynthetic clay liner is composed of high dilatability of sodium base bentonite filling between the special composite geotextile and nonwoven fabric, made by the method of acupuncture or suture composite impervious material.
Geosynthetic clay liner is composed of high dilatability of sodium base bentonite filling between the special composite geotextile and nonwoven fabric, made by the method of acupuncture or suture composite impervious material. Use acupuncture into geosynthetic clay liner can form many small fiber space, make the bentonite particles can't flow in one direction, when under the influence of water within the mat forming uniform density of colloidal waterproof layer, prevent the leakage of water. For different projects,it can combine HDPE liner for better waterproof.
Bentonite has the expansion of the water characteristics. General calcium base bentonite expands, its expansion is only about 3 times their own size; And sodium base bentonite adsorption 5 times its own weight of water in case of water, Volume expansion to the original 15 to 17 times above; Lock sodium base bentonite in the middle of the two layers of geosynthetic materials, protecting and strengthening the role of, Make the GCL has a certain overall shear strength.
